ROQ PRIMER HYBRID

ROQ Primer Hybrid automatically applies pre-treatment to the garments that are going to be printed, preparing them for direct-to-garment digital printing.

Technical Specs
Automatically pretreats garments for direct-to-garment digital printing;
Uniform spraying (excluding the “dew” effect);
Perfect synchronization with ROQHYBRID and ROQ automatic screen printing machines;
Quick and easy set-up;
Maximum coating area 625x830mm;
Pretreatment liquid tank of 5lts;
Individual “On/Off” selection possibility of each pulverizer nozzle;
Easy adjustment of the: height, width and pulverization length; pressure and flow coating and advance speed;
Semi-automatic circuit cleaning system;
Includes an integrated waste collection which is fitted under the pallet.
Description

ROQ Primer Hybrid is extremely easy to operate, due to the in-built electronic control console. From here you can select the spray nozzles that you want, as well as control the amount of liquid sprayed through the speed of advance or retreat of the sprayers.

For better adjustment of the spraying area, the ROQ Primer Hybrid allows for adjustment of height, width, and length.

It has a maximum spraying area of 625x830mm.

The ROQ Primer Hybrid comes equipped with a semiautomatic circuit cleaning system.

It has 3 tanks with a capacity of 5 liters each, being: 1 for pre-treatment liquid, 1 for cleaning liquid, and 1 for waste.

As the ROQ Primer Hybrid works in sync with the ROQ Hybrid digital printing machine and other ROQ screen-printing machines, this allows for high productivity and quality gains.

ROQ Primer Hybrid, the module that gains you time and adds value to your work!

ROQ PRIMER HYBRID in action
